Specifications
|
Product Model |
RSIE-XXX |
|
Flash Type |
MLC |
|
Capacity |
128GB~2TB |
|
Sequential Read（MAX） |
Up to 560MB/s |
|
Sequential Write（MAX） |
Up to 480MB/s |
|
4K Random Read |
65090 IOPS |
|
4K Random Write |
65200 IOPS |
|
Operating Temperature |
-20°C ~ 70°C, -40°C ~ 85°C |
|
Storage Temperature |
-55°C ~ +95°C |
|
Humidity |
5%-95% RH non-condensing |
|
Shock |
1500G/0.5ms |
|
Vibration |
80Hz~2000Hz/20G |
|
Operating Voltage |
DC 5V±5% |
|
Power Consumption（MAX） |
4.2W |
|
Dimensions |
L100.4mm*W70mm*H7.0mm ±0.15mm |
|
MTBF |
2 million hours |
Aerospace/Embedded/Server/Surveillance
